Features :
*Multiple functions with Auto / Manual ranges.
*Large LCD display, 4,000 Counts update 3/sec
*Main Measurements : Frequency, Temperature, AC/DC A-V-Ohm , capacitance, Diode & Continuity , duty cycle
*Frequency : 50Hz to 100Khz
*Temperature : -55C to 400C
*Capacitance : 0.01nF to 100uF
*AC Volts : 0.1mV to 1,000V
*DC Volts : 0.1mV to 1,000V
*AC Current : 0.1uA to 10A
*DC Current : 0.1UA to 10A
*Resistance : 0.1 ohm to 40Mohm
*Duty Cycle : 0.1% to 99.9%
*Data Hold Function
*Both Auto range and Manual range Selectable
*Overrange protection for all ranges
*Polarity Indication : Indicates negative polarity
*Overflow Indication
*Sleep Mode / Auto Power off / Low Battery Indication
Specifications :
*Frequency : 50 / 500 / 5K /50K / 100KHz , +/- 0.1% + 3
*Temperature : -55C to 400C , 2% to 9 % +/- 2C
*Capacitance : 50nF / 200nF / 2uF / 20uF / 200uF / 20mF , +/-2% +5
*DC Volt : 400mV / 4V / 40V / 400V / 1000V , +/-1.0% + 10
*AC Volt : 400mV / 4V / 40V / 400V / 1000V, +/- 3.0% + 3
*DC Current : 400uA / 4,000uA / 40mA / 400mA / 4A / 10A , +/- 1.5% + 3
*AC Current : 400uA / 4,000uA / 40mA / 400mA / 4A / 10A , +/- 1.5% + 3
*Resistance : 400 / 4K / 40K / 400K / 4M / 40M Ohm , +/- 0.5% + 3
*Duty Cycle : 0.1% to 99.9% , +/-1%
*Continuity Test with Alert
*Diode Test
*Power Supply : 2 x AA 1.5V Battery
*Dimension : 180 x 89 x 51.5mm
*Accessories : Test leads , Operation Manual
